Our Company “Allied Civil and Interior solutions” have been at the forefront of commercial and residential refurbishments for over 12 years, working in partnership with architects, designers and individuals to create stunning and exciting places to live, work and play. We have built an enviable reputation for high quality work, focused project management, attention to detail and stringent budget control.
⊃ Evaluation
⊃ Asset Evaluation
⊃ Design and Build
⊃ Project Management
⊃ High quality Refurbishment and Modernisation
⊃ Mechanical and Electrical works including design
⊃ Structural works including design
⊃ Smart management system including fire safety, security, and access control
We offer full industrial and commercial facilities through our own team of highly experienced professionals and a range of trusted specialist contractors. This close-knit team work together to deliver smart and efficient industrial and commercial building assets:
⊃ Exterior, interior design and layouts
⊃ Industrial plant layouts
⊃ Structural Repairs
⊃ Landscape
⊃ Firefighting work
⊃ Demolition
⊃ Waterproofing
⊃ FRP/ Window work
⊃ Building Construction
⊃ MEP Designs & Implementation
⊃ IT Network and cabling
⊃ Industrial asset refurbishment including electro-mechanics & automation
Industrial/ Commercial / hospitality / interior / landscape / complete furnishings / delivery with full precision.
Industrial Building/ Machineries.
Industrial Building/ Machineries/ installation/ commissioning/ refurbishment.
nstallation/ assessment.
Visual inspection (Co-Op Housing Society) of all visible structural parts (Column, beam, slab) , external facades of the building, ancillary structures like Pump house, water tank etc. record our observations for structural distresses in the structural components like deflections in RCC/ Steel/ Timber members like column, beams, slabs, cracks in the structural members & also for items of maintenance like leakages/seepages, terrace water proofing etc. & suggest remedial measures to be taken for improving the durability of the structure as a whole to enhance its future life
Rebound Hammer Test For determining the estemated
compressive strength of concrete and uniformity of
concrete in terms of surface hardness as per IS 13311 (Part2)-1992, ASTM C 805-02, BS 6089: 1981 and BS 1881: part
202, BSEN: 13791, also establishing correlation chart
between rebound hammer and other confirmatory test for
estemated in-situ strength of concrete.
Measuring the Half Cell Potential readings with wheel
electrode at the nodes of pre-marked grip points on
concrete surface in a suitable grip for determining the
probability of corrosion activity of embedded steel
reinforcement in concrete with specified half-cell electrode
in accordance with ASTM C876-1980.
Measurement of Carbonation Depth by Phenolphthalein
Chemical at selected locations on RCC members of the
structures covered under the study to see the depth of
carbonation as per BS EN 14630:2006, BS EN 13295:2004.
Ratio of carbonation depth to cover depth is also measured
to check the intensity of carbonation atack on steel bar.
Preparation of Structural Audit Report which includes: A) The findings from detailed Visual Inspection in the form of Observations, Photographic Records and Critical Areas B) Non-destructive test results & their interpretation to assess current state of condition & levels of deterioration C) Suggested economical viable remedial measures to restore structural stability and increase durability/ residual life of building etc.
